Items/Model
TS1000
Principle
Solid Waste Incineration Treatment
Burn Rate
Average 1000kg/hour
Feed Capacity
Average 6000kg/feeding
Control Mode
PLC(Programmable Logic Controller Incinerator)
Combustion Chamber
4800Liter
Internal Dimensions
400*120*100 cm
Secondary Chamber
1000Liter
Feed Mode
Manual/Forklift
Voltage
220V/380V
Power
8.0Kw
Oil Consumption (kg/hour)
Average 67(DO)
Gas Consumption (m3/hour)
***
Temperature Monitor
Digital Display
Temperature Protection
Yes
Oil Tank
800Liter
Feed Door
300x120cm(Electric Opening)
Chimney
6Meter
Chimney Type
Stainless Steel
1st. Chamber Temperature
800℃–1000℃
2nd. Chamber Temperature
1000℃-1200℃
Residency Time
2.0 Sec.
Gross Weight
20000kg
External Dimensions
700x220x320cm(without chimney)
